THC63LVD827

Overview

The THC63LVD827 transmitter is designed to support pixel data transmission of up to 1080p/1920×1440 resolutions between Host and Flat Panel Display, adopting small package, suited to tablet and laptop PC such as high-resolution mobile devices.

  • LVCMOS to LVDS Conversion
  • LVCMOS Parallel input
    27bits/pixel
    172M pixel/sec.(Clock Freq. 8 to 174MHz)
    1.8V/2.5V/3.3V input supported
    Input clock edge selectable
  • 4ch LVDS 2ports (Dual Pixel Link)output
    1.22Gbps/ch
    LVDS swing mode to reduce EMI
  • Power Supply:1.8V
    IOVCC 1.8/2.5/3.3V selectable
  • Package:VFBGA72
    World smallest package of equivalent products (7mmx7mm)
  • Operating Temperature:-40 to 85℃
  • The highest level power consumption
    Typ. 83mW at WUXGA 60Hz
  • Recommended Rx:
    THC63LVD1022
    THC63LVD1024
