News THine Introduces THEIA-CAM™ 13MP PDAF Camera Kit for NVIDIA® Jetson Orin™ NX/Nano

2024.04.24 Release
NVIDIA® Jetson™ Orin Platform Users Can Now Quickly & Easily Integrate THine’s Leading-Edge Imaging Capabilities
Applications include embedded vision systems, medical scopes, AR/VR systems, barcode scanners, vision assistive glasses, drones, surveillance cameras, body cams, USB webcams, biometric devices, and proof of concept for platform development for AI and IoT vision systems.

Santa Clara and Tokyo (April 24th, 2024) –THine Electronics, Inc. (Tokyo Stock Exchange: 6769, “THine”), the global leader in high-speed serial interface and provider of mixed-signal LSI as well as valuable AI/IoT-based solutions, and THine Solutions, Inc., a subsidiary of THine, today announced that the new THEIA-CAM™ 13MP PDAF Camera, THSCJ101, for NVIDIA® Jetson Orin™ NX and Jetson Orin™ Nano platforms. Along with its pre-optimized ISP firmware and Linux driver, Jetson users are now able to easily integrate advanced imaging capabilities into their systems.


The THSCJ101 Kit is a Camera reference design kit for embedded camera applications using the NVIDIA® Jetson Orin™ NX or the Jetson Orin™ Nano platform. The THSCJ101 Kit is based on THine’s THP7312-P Image Signal Processor (ISP) and Sony’s IMX258 13MP CMOS PDAF image sensor.

THine’s optimized ISP firmware provides ultra-quick autofocus using Phase Detection Autofocus (PDAF) technology and Best-in-Class image quality. The Kit hardware includes all items required to interface with Jetson Orin™ carrier boards with 22-pin MIPI CSI-2 input connector, including a Camera Board in an acrylic case and a Flat Flexible Cable.

Video4Linux2 (V4L2) driver for the THSCJ101 is also available to control various video functions. The performance of each Kit is repeatable for use in high volume production due to our production process to characterize the image parameters of each image sensor and to calibrate the image signal processing to compensate for variation from sensor to sensor.

All technical information including the reference circuit schematics, ISP firmware, and V4L2 Driver are available to customers.

Also, for customers that require unique image performance features, THine can provide a GUI based software development tool that customizes the ISP firmware and/or the image sensor selection. As a result, the THSCJ101 can accelerate NVIDIA® Jetson Orin™ NX/Nano platform users’ time-to-market without expensive integration costs or additional effort for developing embedded camera systems.

“We are providing the quickest and most reliable integration of Best-in-Class image quality and imaging performance into the world-leading AI platform,” said Tak Iizuka, Chief Solution Architect of THine Solutions, Inc. “By bypassing the camera system development and image quality tuning hassle as well as all in-production camera issues, AI system designers are able to focus on the AI development relying on our THEIA-CAM™ support.”

THSCJ101 Key Features

  • Designed for NVIDIA® Jetson Orin™ NX/Nano
  • Various High Resolution options including but not limited to 13MP at 20fps, 4K2K at 30fps, and 1080p at 60fps, in YUV422 format.
  • Ultra-Quick Phase Detection Autofocus (PDAF)
  • Best-in-Class Image Quality with well-optimized Auto White Balance and Auto Exposure
  • Perfect Unit-to-Unit Image Quality for High Volume Production
  • Single 1.38” x 1.38” (35mm x 35mm) Camera Board

About THEIA-CAM™ Family
THEIA-CAM™ is designed for embedded vision systems. Using and optimizing THine’s own ISP, THine offers Best-in-Class image quality and high production quality suitable for any project phase from proof of concept to high volume production. THEIA-CAM™ supports various Operating Systems including Windows®, macOS®, Android™, and Linux®, and various platforms including Raspberry Pi, Jetson Orin™, i.MX 8M families, and MediaTek Genio series. THEIA-CAM™ addresses wide-ranging camera applications including but not limited to AI + IoT devices, AR Glasses, Barcode Reading Devices, Biometric Devices, Bodycams, Document Scanners, Machine Vision systems, Medical Scopes, Microscopes, Surveillance Cameras, Vision Assistance Glasses, and Webcams.

The THSCJ101 is available for purchase at Amazon and Digi-Key.
➢    [Amazon]
➢    [Digi-Key]

About THine Electronics
THine Electronics Incorporated is a fabless semiconductor manufacturer that provides innovative mixed signal LSI and analog technologies. The technologies provided include V-by-One® HS plus, LVDS, other high-speed data signaling, ISP, timing controller, analog-to-digital converter, power management, and drivers for LEDs/motors as well as AI/IoT/M2M solution through Cathay Tri-Tech, Inc.
THine is headquartered in Tokyo, and has subsidiaries in Taipei, Seoul, Hong Kong, Shenzhen, Shanghai, and Santa Clara. THine is listed on Tokyo Stock Exchange under the security code of 6769.  For more information, please visit

#   #   #

All trademarks and registered trademarks are the property of their respective owners.
